Description Description PoE Power Supply PoE StandardIEEE 802.3af, IEEE 802.3at PoE Power PinSupports 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply PoE PortPorts 1 to 8 Port Power30 W PoE Power Pudget60 W Power Consumption65 W Network Parameters Port Number8 × 100 Mbps PoE ports, 1 × 100 Mbps Ethernet port Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x Forwarding ModeStore-and-forward switching Working ModeStandard mode (default); Extend mode High Priority PortsPorts 1 to 2 Ports For Long-Distance TransmissionPorts 1 to 8 MAC Address Table2 K Switching Capacity8 Gbps Packet Forwarding Rate339 Mpps Internal Cache1 Mbits General ShellMetal material, fan-free design Gross Weight89 kg (1.96 lb) Net Weight35 kg (0.77 lb) Dimension (L × H × D)170 mm × 27.6 mm × 93.1 mm (6.7” × 1.1” × 3.7”) Operating Temperature-10 °C to 55 °C (14 °F to 131 °F) Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F) Operating Humidity5% to 95% (no condensation) Storage Humidity5% to 95% (no condensation) Power Supply48 VDC, 1.35 A Power Consumption In Idle5 W Approval
