Tenda F9 600Mbps Whole-Home Coverage WiFi Router

Tenda F9 600Mbps High Speed and whole-home coverage Wi-Fi router,Compared to 450Mbps and 300Mbps products, it’s transmission is more efficient and smooth,It support Smartphone APP remote management, you can manage your device at anytime and anywhere. 4*6dBi High-gain omnidirectional antennas, incredible Wi-Fi coverage and reliability Standard&Protocol IEEE802.11b,IEEE 802.11g, IEEE 802.11n Interface 1*10/100Mbps WAN port 3*10/100Mbps LAN ports Button 1*WPS/RST,1*WIFI Indicator SYS 、WiFi、 1、 2、 3、 WAN 、 WPS Chipset Realtek Flash 2MB Memory 16MB Output Power 9V1A Plug Type Chinese-standard American-standard British-standard European-standard Power Consumption No-load 1.66W Full-load 1.98W Dimension 171.3mm*171.3mm*36.4mm Temperature Operating Temperature:0ºC~40ºC Storage Temperature:-40~70℃ Humidity Operating Humidity:10%~90%, non-condensing Storage Humidity:5%~90%, non-condensing Modulation 802.11b: DSSS ( DBPSK / DQPSK / CCK ) 802.11g: OFDM ( BPSK / QPSK / 16QAM / 64QAM ) 802.11n: OFDM ( BPSK / QPSK / 16QAM / 64QAM ) 802.11n: OFDM ( BPSK / QPSK / 16QAM / 64QAM / 256QAM ) Data Rate 802.11b : 11 Mbps 802.11g : 54 Mbps 802.11n : 450Mbps 802.11n (256QAM): 600Mbps Frequency 2.4~2.4835 GHz Power 802.11b-1M: 21.5 dBm ± 1.5 dBm 802.11g-54M: 17.5 dBm ± 1.5 dBm 802.11n-MCS7: 17 dBm ± 1.5 dBm 802.11n-VHT: 15 dBm ± 1.5 dBm Reception Sensitivity 802.11b-1M: -95 dBm /802.11g-54M: -74 dBm / 802.11n-MCS7: -72 dBm/ 802.11n-VHT: -62 dBm 150Mbps：-70 Bm@10% PER 108Mbps：-73 dBm@10% PER 54Mbps：-74 dBm@10% PER 11Mbps：-86 dBm@8% PER 6Mbps：-90 dBm@10% PER 1Mbps：-95 dBm@8% PER Antenna 4*6dBi external non-detachable Package Content Refer to Quick Installation Guide and User Manual Standard Version RFC768 UDP RFC791 IP RFC792 ICMP RFC793 TCP Channel Bandwidth: 20MHz、20/40MHz Working Mode Router、WISP、Universal Reader、AP Wireless Security WPA-PSK/WPA2-PSK、WPA、WPA2 DHCP Server Support System Tool Internet time、Backup/Recovery、Upgrade Reset to Factory Default Login Password System Log Reboot System Requirements windows 2000 IE 5.0 or Firefox1.0 or higher Network Adapter Downloads # NAME TYPE DATE FILE Download 01 F9 Firmware V12.01.01.45_multi  Firmware 2019-02-15 02 F9 Firmware V12.01.01.43_EN  Firmware 2018-10-12 03 F9 Firmware V12.01.01.42_EN  Firmware 2017-11-17 04 F9 Firmware V12.01.01.36_EN  Firmware 2017-06-30 05 F9 User Guide  Manual 2017-07-07 06 F9 HD Image  HD Image 2017-06-30 07 F9 Datasheet  Datasheet 2017-06-28 08 F9 Installation Guide  Guide 2017-06-30 09 F9 CE  CE 2017-08-07 FAQ 01 F9 and A9 configure authmatic bridging  FAQ 2017-07-07 02 F9-How to control the network speed  FAQ 2017-07-07 03 F9-How to Port Forwarding  FAQ 2017-07-07 04 F9-How to Setup DDNS  FAQ 2017-07-07 05 F9-How to setup remote web management  FAQ 2017-07-07 06 F9-How to setup the black and white list  FAQ 2017-07-07 07 F9-how to setup Universal Repeater  FAQ 2017-07-07 08 F9-How to setup WIFI schedule  FAQ 2017-07-07 09 F9-How to upgrade the router  FAQ 2017-07-07 10 F9-How to use Tenda Route APP to bind router  FAQ 2017-07-07 11 F9-how to Hide the wireless name  FAQ 2017-07-07 12 F9-How to modify wireless name and password  FAQ 2017-07-07 13 F9-How to configure AP mode  FAQ 2017-07-07 14 F9-how to setup the Internet  FAQ 2017-07-07 15 F9-how to setup WISP  FAQ 2017-07-07 16 F9-Frequently Asked Questions  FAQ 2017-07-07
