5-dBi amplified antennas Dual antennas for maximum coverage Wireless Parameter Data Rate2.4 GHz: 300 Mbps Wireless StandardIEEE 802.11b/g/n @2.4 GHz Transmitting Power18 dBm Wireless PerformanceBeamforming supported Receiving Sensitivity 58 ± 2 dB@AC80 -MCS9 84 ± 2 dB@AC80 -MCS0 Antenna2 high gain antennas Hardware Parameter Network Interface4 × RJ45, 10/100 Mbps auto-negotiation LED IndicatorLED indicator ResetReset button Power Supply Method9 VDC, 1 A power adapter power supply Power Specifications9 VDC, 1 A Software Function Application function Wireless Router Mode, Wireless Repeater Mode, Client AP, WISP, and AP Mode supported DHCP Server supported Guest Network Configuration supported Signal Adjustment supported WiFi Schedule supported Security ModeWPA-PSK/WPA2-PSK, WPA/WPA2 Security MechanismHide SSID Management MethodWeb UpgradeWeb Update and Upgrade System LogSystem log WAN ModeDHCP,Static IP,PPPoE General Product Dimension (W × H × D)174.82 mm × 96.45 mm × 181.06 mm (6.88″× 3.80″× 7.13″) Package Dimension (W × H × D)231 mm × 203 mm × 51 mm (9.09″× 7.99″× 2.01″) Net Weight0.134 kg (0.295 lb) Packing ListWireless Router x 1, Ethernet cable × 1, Quick installation guide × 1 Packing MethodSingle pack Working Temperature0 ℃ to 40 ℃ (32 ℉ to 104 ℉) Working Humidity10% to 90% RH non-condensing Storage Temperature-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) Storage Humidity5% to 90% RH non-condensing Installation ModeDesktop installation Max. Power Consumption≤ 5.4 W Gross Weight0.634 kg (1.398 lb)
