Specifications Details Product code RBSXTR&R11e-LTE Architecture MIPSBE CPU QCA9531 CPU core count 1 CPU nominal frequency 650 MHz Switch chip model QCA9531 Dimensions 140 x 140 x 103 mm RouterOS license 3 Operating System RouterOS Size of RAM 64 MB Storage size 16 MB Storage type FLASH MTBF Approximately 200’000 hours at 25C Tested ambient temperature -40°C to 50°C Powering Details Number of DC inputs 1 (PoE-IN) Max power consumption 22 W Max power consumption without attachments 5 W Cooling type Passive PoE in 802.3af/at PoE in input Voltage 12-57 V PoE-out Details PoE-out ports Ether2 PoE out Passive PoE up to 57V Max out per port output (input 18-30 V) 600 mA Max out per port output (input 30-57 V) 400 mA Max total out (A) 600 mA Mobile Details 2G Category Class12 2G bands 2 (1900MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) 3G Category R7 (21Mbps Downlinks, 5.76Mbps Uplink) 3G bands 1 (2100MHz) / 2 (1900MHz) / 5 (850MHz) / 8 (900MHz) LTE Category 4 (150Mbps Downlink, 50Mbps Uplink) LTE FDD bands 1 (2100MHz) / 2 (1900MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) LTE TDD bands 38 (2600MHz) / 40 (2300MHz) TAC 35565409 Ethernet Details 10/100 Ethernet ports 2
